Stainless Steel Sink Unit with Stainless Steel Sink with Two Working Bowls and Quick-Release Service Panel
This model is a specialized sanitary sink designed for use in production areas with increased hygiene requirements. The structure is manufactured from satin-finished stainless steel AISI 304 or AISI 316L and is intended for cleaning process tools, change parts, containers, and equipment components used in pharmaceutical, biotechnology, and food production.
The sink is equipped with two isolated deep bowls, allowing separation of pre-cleaning and final sanitation processes. The integrated drainage system provides controlled water discharge, while the removable front service panel offers quick access to the internal space, siphons, and utilities, significantly simplifying maintenance and routine sanitary inspection.
Upon request, the unit can be supplemented with a rear backsplash, wall-mounted or integrated shelves, as well as a cabinet for storing cleaning agents and accessories. Adjustable vibration-damping feet compensate for uneven floors and ensure stable operation under intensive use.
🔧 Technical parameters:
- Number of working zones: two independent bowls
- Material: stainless steel AISI 304 / AISI 316L
- Bowl depth: up to 400 mm
- Front panel: quick-release, service type
- Drainage system: integrated, connected to utilities
- Temperature resistance: up to +120 °C
- Dimensional execution: custom-made
- Feet: adjustable, vibration-damping
- Regulatory compliance: GMP, HACCP, ISO
✅ Key advantages:
- the sink ensures clear separation of sanitation operations, reducing the risk of cross-contamination
- the design allows fast cleaning and inspection without dismantling the equipment
- the materials used are resistant to aggressive detergents and disinfectants, high humidity, and temperature loads
- individual configuration options allow precise adaptation to the technological process and room layout.
We design and manufacture sinks according to individual technical specifications, taking into account the type of equipment, sanitation regimes, and internal operating standards. Upon request, we provide a 3D model, detailed drawings, and an accurate cost estimate.
