Feed Screw for Pharmaceutical Equipment
The feed screw is used in filling, capping, inspection, dosing, and labeling systems where synchronized container transport without displacement or product damage is critically important.
The optimized helical profile geometry creates a stable container movement path between machine stations, eliminating jerks, misalignment, and uncontrolled flow interruptions.
The solution is suitable for high-speed pharmaceutical equipment handling glass ampoules, plastic vials, cartridges, and syringes.
🔧 Manufacturing Technology
Precision CNC Machining
Each feed screw is manufactured using high-precision CNC machining combined with multi-stage geometric inspection.
The production process includes:
- precision machining of the raw blank
- generation of the helical groove with controlled pitch
- machining of transition areas
- polishing of the working surface
- runout and concentricity inspection
Precise profile synchronization ensures reliable feed screw operation even on high-speed production lines with minimal process tolerances.
Surface and Geometry Control
Final surface finishing is performed to: Ra ≤ 0.4 µm
The polished surface:
- reduces friction coefficient
- prevents contamination buildup
- minimizes wear of mating components
- facilitates sanitary cleaning procedures
✔️ Materials
Pharmaceutical-grade engineering polymers are used for manufacturing:
POM (Delrin)
- high rigidity
- dimensional stability
- excellent machining accuracy
- low moisture absorption
UHMW-PE
- increased wear resistance
- ultra-low friction coefficient
- impact resistance
- chemical inertness
The materials maintain stable performance characteristics when exposed to:
- alcohol-based solutions
- disinfectants
- cleaning chemicals
- CIP/SIP environments
Each DATAPHARM feed screw is individually engineered according to:
- equipment model
- container type
- production line capacity
📐 Technical Specifications:
- Material: POM (Delrin) / UHMW-PE
- Application: transport of ampoules, vials, and syringes
- Machining accuracy: ±0.02 mm
- Surface finish: polished to Ra ≤ 0.4 µm
- Color: white / natural
- Temperature resistance: up to +100 °C
- Resistance to disinfectants: ≥ 10,000 cycles
- Options: with or without metal bushing
- Manufacturing based on customer drawings or samples
✅ Advantages:
- high-precision container positioning
- stable operation at high production speeds
- reduced vibration load
- minimal noise level
- compatibility with OEM equipment
- no machine modification required
- resistance to aggressive chemical environments
- extended service life
- compliance with GMP and FDA requirements
📌 Applications:
- pharmaceutical filling lines
- capping machines
- inspection systems
- blister packaging lines
- packaging equipment
- cosmetic and food production
DATAPHARM manufactures conveying and format components for pharmaceutical equipment in accordance with GMP requirements, precision engineering standards, and high-speed production processes.
Each component undergoes inspection for geometry, surface quality, and compatibility with customer equipment.
📩 Send your drawing, sample, or equipment parameters — DATAPHARM engineers will prepare a technical solution and commercial proposal tailored to your production line.
