Stainless Steel Process Vessel 100 L with Hinged Lid
The DATAPHARM 100 L hinged-lid vessel is a reliable solution for pharmaceutical, chemical, and food industries requiring hygiene, safety, and operator convenience.
Both the body and lid are made of AISI 304 stainless steel (optionally AISI 316L) with an internal mirror polish (Ra ≤ 0.8 µm) providing easy cleaning and chemical resistance. The hinged lid with a lock system guarantees secure sealing and quick access for loading and unloading.
Equipped with ergonomic side handles, the vessel can also be fitted with a drain valve, outlet, or fitting. Its construction resists temperature variations and complies with GMP and ISO 9001 requirements.
⚙️ Specifications:
- Capacity: 100 L
- Material: Stainless steel AISI 304 / AISI 316L
- Wall thickness: 1.2–1.5 mm
- Lid type: Hinged with locking mechanism
- Handles: Side, welded, stainless steel
- Seal: Silicone or PTFE upon request
- Surface finish: Polished to Ra ≤ 0.8 µm
- Working temperature: up to +120 °C
- Additional options:
– Drain outlet, valve, or fitting
– Volume or serial number marking
– Mobile version with castors
– CIP connections and custom dimensions
✅ Advantages:
- Airtight and safe design
- Easy-access hinged lid with secure lock
- Resistant to disinfectants and active chemicals
- Smooth surfaces without dead zones
- GMP and ISO 9001 compliant
- Customizable for specific process requirements
Can be used as:
- Container for liquid or bulk components
- Transport vessel for intermediates and solutions
- Buffer tank in a production line
- Sanitary or process liquid container
🌟 Choose DATAPHARM 100 L with hinged lid — the perfect balance of hygiene, speed, and reliability in your production.
