Features:
Free of maintenances
Compact and portable
High precise casting body
Flexible combination of L type and T type design
Inlet and Outlet can be exchangable
No dead angle, Non retention
All line design, in order to reduce pipeline rapids and
pressure drop
Small operating torque
Hand lever can be installed on the side of the valve body, no matter of the flow direction
Pressure: 10 bar
Temperature: -60~ 180 degree
Body type: 3 way (L type and T type)
Working mode: manual type, electrical type, pneumatic type
Gaskets: PTFE, EPDM
Easy cleaning, easy maintenance, light weight
Connection end: weld, tri-clamp, union, flange, male threading, female threading
Standard: DIN, SMS, ISO, 3A, IDF
Material: SS304, SS316L
Inside surface finish: Ra 0.4
Outside surface finish: Ra 0.6
Size: DN15-DN100, 1/2”-4”
Application: food, pharmacy, chemical or any food processing industries.
