Pharmaceutical Stainless Steel Drying Rack for Cleanroom Use
The drying rack is designed for controlled gravity drying of tools, laboratory glassware, change parts, and format components after washing and disinfection processes in classified production areas. The structure enables unrestricted airflow around items and eliminates moisture retention zones, reducing the risk of secondary contamination.
The frame is manufactured from corrosion-resistant stainless steel grade AISI 304 or AISI 316L, selected according to environmental and chemical exposure conditions. Load-bearing elements are fabricated from structural tubing with TIG welding, followed by weld grinding and passivation. Surface finish is brushed or electropolished with roughness controlled in accordance with project specifications.
Shelf sections are formed from calibrated rods or profiled elements with calculated spacing determined by load and geometry of stored components.
The open design provides:
- uniform air circulation;
- accelerated evaporation of residual moisture;
- direct visual cleanliness inspection;
- elimination of horizontal surfaces that retain water.
Allowable distributed load per tier is individually calculated (typical range 80–150 kg per level in standard configuration).
Depending on facility layout, the unit can be supplied as:
- stationary version with adjustable feet for floor leveling;
- mobile configuration equipped with industrial swivel castors and brake locks.
The structural geometry eliminates enclosed cavities and inaccessible areas, facilitating sanitary cleaning and complying with hygienic design principles.
Number of tiers (3–7), vertical spacing, overall dimensions, and optional accessories are defined by technical specification and cleanroom layout.
🔧 Technical Parameters:
- Material: AISI 304 / AISI 316L
- Construction type: welded hygienic design
- Welding method: TIG with grinding and passivation
- Surface finish: brushed / electropolished
- Number of tiers: 3–7
- Load capacity per tier: individually calculated
- Supports: adjustable feet or braked castors
- Configuration: according to technical specification
- Compliance: GMP, HACCP, ISO 14644
✅ Engineering Advantages:
- Controlled drying without moisture accumulation zones
- Enhanced corrosion resistance under frequent sanitation
- Design focused on cross-contamination risk mitigation
- Adaptable to specific technological processes
- Long operational life with maintained dimensional stability
DATAPHARM delivers a full engineering cycle — from structural calculation and 3D modeling to manufacturing and installation, accompanied by complete technical documentation.
📩 Provide room parameters and expected load — we will prepare a tailored engineering solution with structural calculations and specification.
