2CMP Tri-Clamp 90° Food-Grade Elbow

2CMP Tri-Clamp 90° Food-Grade Elbow

Article number:

Available for pre-order

Size

DN15
  • DN15
  • DN20
  • DN25
  • DN32
  • DN40
  • DN50
  • DN65
  • DN80
  • DN100

Material

AISI 304
  • AISI 304
  • AISI 316 L
Send a request
Description

The 2CMP Tri-Clamp 90° Elbow is made from SS304 or SS316L and comes in sizes DN10–300 with welded, clamped, or threaded connections. It features mirror or matte finishes, internal Ra 0.4 and external Ra 0.8, and meets DIN, SMS, 3A, and other hygienic standards. Ideal for food, beverage, dairy, pharmaceutical, and chemical applications.

Full description

Fearure of the Stainless Steel Food Equipment 2CMP tri-clamp 90 degree elbow:

Connection end: welded, clamped, threaded, union type,

Standard: DIN, SMS, ISO, 3A, BPE, IDF, AS, BS

Size: DN10-300, 1/2”-10”

Material: SS304, SS316L

Made from welded pipe or seamless pipe as per requirement

Surface finish: Mirror, matt type as per requirement

Inside Ra 0.4, Out side Ra 0.8

Roundness, thickness equality to meet international food grade standard

Application: Food, beverage, dairy, pharmacy, chemical or any food processing industries.
