Stainless Steel Rack for Cassette and Process Tray Storage in Clean Areas
The rack is engineered for structured storage of cassette systems, carrier trays, and format tooling within controlled production environments. It is intended for pharmaceutical, sterile, and laboratory facilities where dimensional stability, secure positioning, and prevention of unintended movement during storage are essential.
The structure is manufactured from corrosion- and chemical-resistant stainless steel AISI 304 or AISI 316L, selected according to environmental exposure and sanitation intensity. The material maintains mechanical integrity under hot steam, alkaline agents, alcohol-based disinfectants, and high humidity conditions.
The load-bearing frame is fabricated from rectangular tubing using hygienic TIG welding, followed by weld finishing and surface passivation. The design eliminates enclosed cavities and contamination-prone areas. Surface treatment may include grinding or electropolishing with controlled roughness parameters.
Guide modules are custom-designed to match specific cassette geometry and provide:
- precise positioning without misalignment;
- uniform load distribution;
- dimensional stability during long-term storage;
- simplified visual inspection.
Perforated guides are available to enhance airflow and reduce condensation formation. The number of tiers (3–10), vertical spacing, and overall configuration are determined based on cassette dimensions and facility logistics.
The rack can be supplied in stationary or modular configuration. Supports include adjustable leveling elements, with optional anti-vibration inserts or caster assemblies.
The structure is designed to withstand dynamic operational loads and allows rapid sanitary cleaning without dismantling primary components.
🔧 Technical Parameters:
- Application: storage of cassette systems and carrier trays
- Material: AISI 304 / AISI 316L
- Design type: stationary or modular
- Number of tiers: 3–10
- Guide type: solid or perforated
- Load capacity per tier: up to 50 kg (evenly distributed)
- Supports: adjustable, optional anti-vibration
- Surface finish: ground or electropolished
- Additional features: stops, labeling panels, casters
- Dimensions: custom engineered
- Compliance: GMP, HACCP, ISO 14644
✅ Engineering Advantages:
- Stable cassette positioning without play
- High resistance to aggressive sanitation cycles
- Custom design for non-standard formats
- Hygienic structure without contamination traps
- Long-term durability under intensive use
- Optimized storage in controlled environments
📩 Provide cassette specifications and load data — we will prepare a tailored engineering solution with structural calculation and detailed documentation.
