Stainless Steel Sanitary Manual Multi-Port Straight Way Ball Valve

Stainless Steel Sanitary Manual Multi-Port Straight Way Ball Valve

Article number: JN-BLV2009

Available

Size

DN32
  • DN15
  • DN20
  • DN25
  • DN32
  • DN40
  • DN50

Material

SS316L
  • SS304
  • SS316L

Gasket material

EPDM
  • PTFE
  • EPDM
Send a request
Description

A reliable choice for modern processing lines!

This manual multi-port stainless steel hygienic valve features a full-bore, straight-through design that eliminates flow resistance. Perfect for handling viscous and particulate fluids. Easy to clean andmaintain, resistant to high pressure and temperature. A top solution for food, pharmaceutical and chemical applications.

Size
Full description
Stainless Steel Sanitary Manual Multi-Port Straight Way Ball Valve
Features:

High precision casting body and flange

Full bore and «non-dead» angle design

Pressure: up to 1000 PSI

Temperature range: -60 to 180 °C

Working modes: manual, electric, pneumatic

Gaskets: PTFE, EPDM

Easy cleaning and maintenance

Connection types: weld, tri-clamp, union, flange, male/female threading

Standards: DIN, SMS, ISO, 3A, IDF

Materials: SS304, SS316L

Inside surface finish: Ra 0.4

Outside surface finish: Ra 0.6

Size range: DN15–DN100, 1/2”–4”

Applications: food, dairy, pharmaceutical, chemical and food processing industries.
