Mini Diaphragm Sampling Valve

Mini Diaphragm Sampling Valve

Article number:

Available for pre-order

Material

AISI 304
  • AISI 304
  • AISI 316 L

Gaskets

EPDM
  • EPDM
  • Silicone
Send a request
Description

The Stainless Steel Sanitary Mini Diaphragm Sampling Valve is made of SS304 or SS316L with silicone or EPDM gaskets, offering a long service life and easy sterilization by alcohol or steam. It allows sampling during production without stopping the process and prevents second-time contamination. The valve has a maximum pressure of 1000 kPa (closed) and a temperature range of up to 130°C, with internal and external surfaces of Ra 0.5um and Ra 0.8um, respectively.

Full description

Features of the Stainless Steel Sanitary Mini Diaphragm Sampling Valve:

The valve body: SS304 or SS316L Valve head: SS304.

Gasket: Silicone, EPDM.Max. pressure: 1000kpa ( valve close).

Max. pressure: 500Kpa for silicone  ( valve open)
                        1000Kpa for stainless steel part  ( valve open).

Max. temperature: 130 degree

Long service life

Easy to sterilize.

Sampling work can be done any time during production, no need to stop production.

Sterilization by alcohol or steam.

Material sealed by diaphragm directly.

No second -time contamination, bulk or mini sample allowed.

Inside surface: Ra 0.5um

Outside surface: Ra 0.8um
